LINUS

LINUS-S

  • Minimalist design
  • Extendable spray head
  • High quality metal spray
  • High spout for easy filling of pans and vases
  • Design and colour of tap and coloured sink are a perfect match

raw material: brass

brass

colour: volcano grey

chrome
PVD+steel
satin+gold
satin+dark+steel
satin+platinum
anthracite
coffee
white
tartufo
rock+grey
black
volcano+grey
soft+white
black+matt

high spout: Yes | wall mounted: No | high/low-pressure: High Pressure

Article number 526958

Data & Documentation

Data sheet & Documentation

2 spray typesNo

2-handleNo

archetypeL-shape

bridgeNo

filter mixer tapNo

flow rate at 3 bar (l/min)9.56 l

Care Products
Spare parts

Spare parts

Spare parts
ImageArticle numbers & descriptionsPrice
1Lever LINUS /-S volcano grey complete

Art. ID: 124382

Lever LINUS /-S volcano grey complete

£58.49
2Allen screw 2,5 mm and color cap chrome

Art. ID: 128685

Allen screw 2,5 mm and color cap chrome

£6.99
3Locknut cartridge LINUS /-S

Art. ID: 123918

Locknut cartridge LINUS /-S

4Cartridge HP 35 mm K-35A

Art. ID: 121894

Cartridge HP 35 mm K-35A

£35.49
5Seal set LINUS-S /-S-F

Art. ID: 116550

Seal set LINUS-S /-S-F

6Nut holder for angle pipe LINUS-S brass

Art. ID: 117997

Nut holder for angle pipe LINUS-S brass

8Fitting piece spray head LINUS-S / TALOS

Art. ID: 139773

Fitting piece spray head LINUS-S / TALOS

£7.49
9Spray pipe ARGON/ELIPSO/MERKUR/MIRA

Art. ID: 125763

Spray pipe ARGON/ELIPSO/MERKUR/MIRA

£45.49
10Seal shower hose ½'' LINUS-S

Art. ID: 139345

Seal shower hose ½'' LINUS-S

£7.49
11Spray head LINUS-S HP volcano grey complete

Art. ID: 124383

Spray head LINUS-S HP volcano grey complete

£78.49
12Sealing

Art. ID: 117502

Sealing

12Jet regulator HP IT M22x1 AF22 BL chrome

Art. ID: 116488

Jet regulator HP IT M22x1 AF22 BL chrome

£13.49
13Locking screw outlet FILO/LINUS/MASTER

Art. ID: 128697

Locking screw outlet FILO/LINUS/MASTER

£7.49
17Assembly set LINUS-S

Art. ID: 123919

Assembly set LINUS-S

18Assembly nut LINUS-S

Art. ID: 123920

Assembly nut LINUS-S

19Stabilization plate ORION/PALLAS/TERA/URANUS

Art. ID: 126945

Stabilization plate ORION/PALLAS/TERA/URANUS

£7.49
20Connection hose without gasket 30 cm

Art. ID: 119786

Connection hose without gasket 30 cm

£30.49
23Ball counter weight 200 gr

Art. ID: 123801

Ball counter weight 200 gr

24Flex.hose 65cm ST B FI EU ⅜-M8x1

Art. ID: 119374

Flex.hose 65cm ST B FI EU ⅜-M8x1

24Flex.hose 70cm ST B FI EU ⅜-M8x1

Art. ID: 123937

Flex.hose 70cm ST B FI EU ⅜-M8x1

25Flex.hose 65cm ST R FI EU ⅜-M8x1

Art. ID: 119375

Flex.hose 65cm ST R FI EU ⅜-M8x1

25Flex.hose 70cm ST R FI EU ⅜-M8x1

Art. ID: 123936

Flex.hose 70cm ST R FI EU ⅜-M8x1

26Filter gasket for corner valve ⅜''

Art. ID: 118840

Filter gasket for corner valve ⅜''

£7.49
27Seal T-piece spray pipe LINUS-S

Art. ID: 139346

Seal T-piece spray pipe LINUS-S

£6.99
28Cover ring LINUS /-S chrome

Art. ID: 123921

Cover ring LINUS /-S chrome

29Non-return valve MASTER-S PROFI

Art. ID: 128741

Non-return valve MASTER-S PROFI

Key for jet regulator/-splitter

Art. ID: 511324

Key for jet regulator/-splitter

Grease for mixer tap 5g Berulub Sihaf 2

Art. ID: 117934

Grease for mixer tap 5g Berulub Sihaf 2

£12.49
Grease for mixer tap 25g Berulub Sihaf 2

Art. ID: 117933

Grease for mixer tap 25g Berulub Sihaf 2

Additional mixer taps stabilisation 60mm

Art. ID: 513383

Additional mixer taps stabilisation 60mm

£21.99
Universal spanner for cartridge cover ring

Art. ID: 139219

Universal spanner for cartridge cover ring

£22.49
Flexible sealing tape

Art. ID: 120055

Flexible sealing tape

Inner waterway LINUS-S cpl. SO

Art. ID: 124200

Inner waterway LINUS-S cpl. SO

£6.99
Spray hose guide for kitchen mixer taps

Art. ID: 511920

Spray hose guide for kitchen mixer taps

£16.99
Additional mixer taps stabilisation 75mm

Art. ID: 513384

Additional mixer taps stabilisation 75mm

Allen key (key size 2.5 mm)

Art. ID: 139188

Allen key (key size 2.5 mm)

FAQ

Frequently Asked Questions

  • Generally speaking, our mixer taps are easy-care and hygienic. This is thanks to their smooth surface, which allows hardly any dirt to settle on it. However, mixer taps do benefit from regularly cleaning. It doesn’t take much effort, but it needs to be done frequently. Take a mild cleaning agent and go over the mixer taps a few times with the soft side of a sponge. Now rub them dry with a microfibre cloth, and you’ll see that your mixer taps are back to being a stand-out feature of your kitchen once again, in just a few simple steps.

  • If your low-pressure mixer tap is dripping slightly, there’s no need to get a plumber in right away. This is completely normal. The reason is that low-pressure mixer taps are normally connected to a boiler. If you have used some warm water, cold water will flow into the boiler to be heated up. The rise in temperature means that the water in the pipe expands. As a result, the rising water pressure causes a small amount of water to be pushed into the mixer tap, where a few drops will escape.

  • Most people will need a high-pressure mixer tap in their home. This is always the case if the water is heated by the central water supply. You can tell whether applies to you if your kitchen has a wall valve for both cold and warm water pipes. You will therefore need a mixer tap that can handle the high water pressure from the pipes. Sometimes, however, your flat or house many not have a central hot water supply. In this case, the water will be heated by a boiler or flow heater. If your home has a flow heater for warm water, you will also need a high pressure mixer tap. A low-pressure mixer tap is required if your warm water is supplied via a boiler. This minimises the pressure from the water pipe and conducts the water at a much lower pressure into the boiler.

  • Our pull-out sprays make your everyday life a little easier. They allow you to get the water to the part of the sink where it is actually needed. Flexible and effective. As such, our hoses are designed for constant movement. Just make sure that the hose does not develop any kinks. This can damage it, causing it to start dripping. If the hose is no longer gliding smoothly back into the body of the tap, this doesn’t mean that you’ve done something wrong. Simply apply a little mixer tap lubricant as soon as the first signs start to show. That should do the trick. The hose will then glide back into place quickly and directly, just as it did before.

  • Imagine standing in the sunshine at the kitchen window and calmly doing the washing up. Our mixer taps make this possible. Just take a look at our detachable, lowerable or collapsible mixer taps. These three concepts allow you to open the window on the other side of your sink easily and in only a few steps.

  • A spraying mixer tap gets water everywhere, not just in the sink bowl. This is usually caused by limescale that has accumulated in the mixer tap. Instead of reaching straight for an aggressive cleaning agent, adding a little citric acid or vinegar to your cleaning water should solve the problem. To clean it, wipe the fine mesh attached to the tap outlet clean. Go over it again with a soft microfibre cloth. The trick to preventing a spraying mixer tap is to clean it regularly, so limescale doesn’t get the chance to build up.

  • Splish, splash: a dripping tap is very annoying. However, there’s no need for agitation. This is either due to limescale deposits in the mixer tap cartridge, or the seals are no longer fit for purpose. Unless you’re very adept at DIY and have a well-equipped toolbox, it’s best to call a sanitary specialist to deal with this. If you’re up to handling it yourself, clean any calcified areas of the seals or mixer tap with citric acid or vinegar. If the seal has become porous it should be replaced using the right tool. Once that’s done, everything in your kitchen will be back in order again.
